DIN3202 Cast Steel Gate Valve is designed and manufactured according to the DIN standard. It is available in various sizes, ranging from DN15 to DN600, and pressure ratings from PN10 to PN64. The valve is suitable for use in a wide range of applications, such as oil and gas, chemical, power generation, and water treatment.

The DIN3202 Cast Steel Gate Valve internal components include the gate, stem, bonnet, and packing:

The gate is made of stainless steel or other corrosion-resistant materials, which ensures that it does not corrode or wear out easily. The stem connects the gate to the handwheel or actuator, which is used to operate the valve. The bonnet is the cover that seals the valve body and prevents leakage. It is made of cast steel or other materials, which provides it with excellent strength and durability. The packing is the material that seals the stem and prevents leakage. It is made of PTFE or other materials that can withstand high temperature and pressure.

QINGDAO FLUIDO have good quality and competitive price for DIN3202 Cast Steel Gate Valve, please contact us, we will provide you with all the information you need and help you choose the right valve for your application.

Technical Specifications of DIN3202 Cast Steel Gate Valve:


Parts and Materials of DIN3202 Cast Steel Gate Valve:
